UBIQUITI AIRMAX M2 NANO STATION UBIQ OUTDOOR

Connect suitable sites or customer premises with the Ubiquiti NanoStation M2. This directional 2.4 GHz airMAX radio combines an integrated antenna with a weather-resistant enclosure and pole-mount installation. Two 10/100 Ethernet ports provide wired connectivity, with 24 V passive PoE supplying power. Select it as part of a compatible wireless-link design with clear line of sight, appropriate channel planning and correctly rated cabling. It is not a Gigabit Ethernet or Wi-Fi 6 device. Confirm link compatibility, mounting and the supplied power accessories with TjTech before installation. Actual link performance depends on the site and configuration.

Model

NSM2

Power

24 V passive PoE

Weight

400 g

Ethernet

2 x 10/100 Mbps RJ45

Dimensions

294 x 31 x 80 mm

Antenna gain

10.4-11.2 dBi

Frequency band

2.4 GHz

Supported voltage

22-27 V DC

Supplied accessories

Confirm current TjTech bundle

Operating temperature

-30 to 75 °C

• 2.4 GHz airMAX radio
• Integrated directional antenna
• Two 10/100 Ethernet ports
• 24 V passive PoE
• Outdoor UV-stabilised enclosure
• Pole-mount installation
• Brand: Ubiquiti
• Type: 2.4 GHz airMAX CPE
• Environment: Indoor / Outdoor
